| A | Ø 15 pipeline | ||||
| 1 | 199000360410 | Right angle joint body | M26×1.5 | ||
| 2 | 190003559386 | Direct connector body | M26×1.5 | ||
| 3 | 190003559778 | hex nut | M26×1.5 | ||
| 4 | 190003559751 | Direct connector body | |||
| 5 | 190003559385 | Direct connector body | |||
| 6 | 190003559668 | Right angle pipe joint | |||
| 7 | 190003559547 | hex nut | M22×1.5 | ||
| B | Ø 12 pipeline | ||||
| 1 | 190003559955 | End right angle joint body | |||
| 2 | 190003559946 | End to end connector body | |||
| 3 | 190003559490 | End to end connector body | |||
| 4 | 190003559948 | Direct connector body | |||
| 5 | 190003559965 | Three way connector body | |||
| 6 | 190003559967 | Three way connector body | |||
| 7 | 190003559958 | Three way connector body | |||
| 8 | 190003559474 | Direct connector body | |||
| 9 | 190003559479 | Straight through board connector body | |||
| 10 | 199100360113 | Right angle through plate joint body | |||
| 11 | 199100360114 | Three way connector body | |||
| 12 | 199100360115 | Three way connector body | |||
| 13 | 199100360116 | Three way connector body | |||
| 14 | 199100360117 | reducing coupling |
