| 24 | 79100360018 | Working cylinder | 2 | ||||||||||||||||||||
| 2526 | Q33208 Q40108 |
Type II all metal hexagonal lock nut flat washer |
2 2 |
||||||||||||||||||||
| 27 | 61000060072 | Spacer sleeve | 1 | ||||||||||||||||||||
| 28 | 99014320156 | bracket assembly | 1 | ||||||||||||||||||||
| 29 | AZ9114320178 | Oil plate assembly | 1 | for i=5.73 6.72 7.49 8.4 9.49 | |||||||||||||||||||
| 30 | 99014320118 99014330208 |
Oil plate assembly Middle axle shell assembly |
1 1 |
for i=4.8 4.42 | |||||||||||||||||||
| DZ9114330208 | Strengthen the middle axle housing assembly | 1 | |||||||||||||||||||||
| 31 | 90003989290 | Bowl shaped blockage | 1 | ||||||||||||||||||||
| 32 | Q2540820 | Cross groove countersunk head screw | 4 | ||||||||||||||||||||
| 33 | 99014330147 | Bow shaped fixed card assembly (top) | 1 | ||||||||||||||||||||
| 34 35 |
680M330015 99014330125 |
O-ring seal Control lever assembly |
1 1 |
||||||||||||||||||||
| 36 37 |
Q1200850F3 61000060084 |
double-ended bolt Spacer liner |
1 1 |
||||||||||||||||||||
| 38 39 40 41 42 43 |
Q150B1025 99014320141 99000330006 90003962021 99014330146 90003810631 |
hex head bolt bearing housing Ventilation port assembly Cone thread hexagonal plug Bow shaped fixed card assembly (bottom) double-ended bolt |
8 1 1 1 1 4 |
||||||||||||||||||||
| 44 | 90003888457 | self-locking nut | 4 | ||||||||||||||||||||
| 45 46 |
Q5210820 90003888459 |
cylindrical pin self-locking nut |
4 4 |
||||||||||||||||||||
