| 1 | 190003888459 | Self-locking nut | 8 | ||||||||||||
| 2 | 190003888458 | Self-locking nut | 21 | ||||||||||||
| 3 | DZ9118521011 DZ9118521012 |
Front spring, left front bracket Front spring, right front bracket |
11 | ||||||||||||
| 4 | Q151B16130TF2 | Hexagon headed bolt-Fine teeth | 1 | ||||||||||||
| 5 | Q151B1460 | Hexagon headed bolt-Fine teeth | 5 | ||||||||||||
| 6 | 190003888457 | Self-locking nut | 28 | ||||||||||||
| 7 | Q151C1275 | Hexagon headed bolt-Fine teeth | 8 | ||||||||||||
| 8 | Q151B1665TF2 | Hexagon headed bolt-Fine teeth | 4 | ||||||||||||
| 9 | 168000520050 | grommet | 24 | ||||||||||||
| 10 | DZ9118529001 DZ9118529002 |
Front steel plate spring assembly (left) Front steel plate spring assembly (right) |
22 | ||||||||||||
| 11 | 199000520078 | bush | 8 | ||||||||||||
| 12 | 199100520065 | spring pin | 11 | ||||||||||||
| DZ9100520007 | spring pin | 1 | |||||||||||||
| 13 | 190003963127 | Metric taper thread grease nozzle | 4 | ||||||||||||
| 14 | 168000520056 | grommet | 16 | ||||||||||||
| 15 | 190003888626 | Self-locking nut | 16 | ||||||||||||
| 16 | 188000520002 | Front spring pressure plate | 4 | ||||||||||||
| 17 | 199000520086 | Front spring riding bolt | 8 | ||||||||||||
| 18 | DZ9118520172 | Front spring limit bracket assembly | 2 | ||||||||||||
| 19 | Q151C1255TF2 | Hexagon headed bolt-Fine teeth | 16 | ||||||||||||
| 20 | 81.96020.6013 | Hollow rubber buffer block | 4 | ||||||||||||
